TAKE A LOOK AT OUR PRESENT INVENTORY LIST

(Please view both this list below and the Categories below also
as they are not the same and you will need to view both
to see our entire list of machinery available)

If you would like to view our most recent inventory listing click here.

If you have trouble opening the word document above, try this link (Click here)
(note on this view photos are not visible)

Note: We buy and sell equipment daily so these list change often
if you don't see what you are looking for give us a call!

Click below on the type of Equipment to view Inventory by Category
(NOTE Some of this equipment may be SOLD and no longer available)

NICE TENTER FRAME AVAILABLE IN OUR INVENTORY!

Tenter Frame / Krantz / 128” wide, yr. 1990
Krantz Tenter Frame, year 1990, S/N 1031770 (will go out to 128” wide, however, was running 120” goods), consisting of:
A) Beam Let-Off, will take 134”, or a small Scray or J-Box or a Tube Let-Off Stand
B) Compensator, 130” wide, 3-roll, 6” diameter rolls
C) 1 – Vertical Wash Box with 4 top rolls and 3 bottom rolls, 132” wide x 6” diameter, with a small nip roll at the exit
D) 50 Gallon Stainless Steel Tank with mixer
E) Kusters 2-Roll Pad, 134” wide, top roll is 10” diameter, rubber, hydraulic, expandable, bottom roll is 15” diameter, rubber, pneumatic, 10 ton, with a swing-away single dip pan, 15 HP DC drive
F) 2-Roll Sky Device
G) Krantz Hybold Tension Device
H) Operators Platform
I) Krantz Tenter Frame, year 1990, S/N 1031770, with overfeed; overfeed roll is 145” wide, with Tandematic plate guides with a Type FR1501 E&L electric guider for rail opening, pinning brushes, combination pin/clip chain, center support system for supporting the fabric, with 20’ entry before the oven (total length of the frame is 100’ long), has edge trimmers at exit (split differential drive at the exit with DC motor drive)
J) Oven, 7 zones, gas fired, Honeywell Actuators with Maxon Valves, the burners go down inside the oven (72’ long), 7 blower motors (1 for each section of housing), 1 exhaust fan which takes care of 4 zones in the entry, 1 exhaust fan which takes care of 3 zones at the exit, with an additional exhaust fan for the last zone
K) Mahlo Weft Straightener, Orthomat Model FMC-9, 4 optical eyes
L) 2-Roll Surface Take-Up
M) 1 Adjustable Dye Beam Take-Up, hydraulic driven
N) Overhead Plaitor
O) Reliance DC Vari-Drive
Overall length of the frame is 143’ long, overall width is 18’ wide.

EMAIL US TO REQUEST PHOTOS OF THE ABOVE TENTER FRAME!

Click here to E-Mail us at info@cteinternational.com
